System with mid-level spreader
Payload 3kg / 6.6lb

  • RC-30

H15 Counterbalance chart
System components
Head: H15 Tripod: RT30B
Spreader: BR-2B Large rubber feet: FP-2B
Case: RC-30
Operation manual
H15 RT30B
BR-2B FP-2B
Specification sheet
HS-150M H15
RT30B BR-2B
FP-2B RC-30
Service parts
H15 RT30B
BR-2B FP-2B
Specifications
Counterbalance range 0.8 to 2kg / 1.7 to 4.4lb (C.G.55mm)
Payload 3kg / 6.6lb
Counterbalance Perfect Balance
Continuous Counterbalance with Illuminated Meter
Pan drag mode Free plus 3 steps
Tilt drag mode Free plus 3 steps
Drag system Multilayered Metal Structure
Tilt angle +90° / -70°
Temperature range -40°C to +60°C / -40°F to +140°F
Bubble level Illuminated
Camera plate Sliding plate compatible
with Manfrotto and Sachtler heads
Sliding range +/-30mm / 1.2"
Long sliding plate Optional
Plate attachment 1/4" screw with video pin
Accessory attachments 1/4" and 3/8" screw holes
Spare screw 1/4" and 3/8" screws
Weight 5.9kg / 13lb
Height 81 to 166cm / 31.9 to 65.4"
Head attachment 75mm bowl
Pipe material Aluminium
Section 2-Stage
H15 Counterbalance chart
